Unidrain Low Profile and High Capacity Outlets
What wet room drain outlet do I need for my project?
Over the last two decades, wet room designs have become very popular and have gone on to replace the traditional plastic tray and cubicle style of bathrooms. Wetrooms give you the scope to achieve a modern, sleek and clean finish. You can create a beautifully tiled floor without the need for a shower tray, enabling a seamless open-plan look to your bathroom. We offer a wide range of wetroom kits and wetroom systems for you to choose from and to design the room that best suits your home.
UniSlope and Unidrain can be supplied with the new self cleaning trap.
Introducing Unidrain - A Scandinavian award winning wet room drain solution.
Unidrain is a market-leading wet room drain across Europe. Unidrain Wall Mounted and Centre Floor Linear Drains can be used with a wide range of outlets, from low profile to high capacity. This provides a great amount of flexibility to suit your floor construction and project requirements. All outlet come with traps which are easy to clean and allow access to the pipework if rodding is required. Unidrain is BBA Approved and complies with EN1253.
Unidrain Outlet Options
Flexible Wetroom Drain Outlet
Product Code: 1416.0050
This is the standard outlet we supply, and it is multi-directional, allowing you to connect your pipework at the front, back, left, and right. It provides a great amount of flexibility when installing on wooden floors, where joist locations can dictate the pipework.
Capacity - 48 l/min
Low Profile Shallow Wetroom Drain Outlets
Product Code: 1417.0050
The shallowest wetroom drain solution by Unidrain. The 1417.0050 outlet is designed for projects where floor depth is an issue and outlets with a 50mm water trap cannot be used. This outlet uses Unidrain's unique mechanical anti-odour barrier, which reduces the depth required to install and makes the slimline outlet possible. Capacity - 36 l/min
NEW - Product Code: 1418.0050
The latest addition to the Unidrain outlet range, the 1418.0050 is the shallowest outlet with a 50mm water trap. It is ideal for projects which require a slimline solution due to small floor voids but require a 50mm water trap. The perfect outlet for POD manufacturing.
Capacity - 32 l/min
Vertical Wetroom Drain Outlets
Product Code: 1312.0050
The shallowest vertical wetroom drain solution by Unidrain. Like this 1417.0050 outlet, it is designed for projects where floor depth is an issue and outlets with a 50mm water trap cannot be used, but require a vertical connection. This outlet uses Unidrain's unique mechanical anti-odour barrier which reduces the depth required to install and makes the slimline outlet possible.
Capacity - 36 l/min
Product Code: 1412.0075
Combining vertical pipework connection with high capacity drainage, the 1412.0075 is ideal for projects with concrete floors which have multiple high flow rate shower heads, jets, rainfall, etc.
Capacity - 90 l/min
High Capacity Flow Rate Wetroom Drains Outlet
Product Code: 1312.0075 + P Trap
The ultimate Unidrain outlet for high-capacity drainage. It uses a P Trap instead of a removable 50mm water trap, which allows water to flow through the pipework faster. The Unidrain P Trap is self cleaning so you do not have to clean it regularly.
Capacity - 102 l/min
What is a wetroom drain water trap, and how does it work?
A water trap is used for all bathroom products, from baths and shower trays to sinks and toilets. The majority of these items will use a U bend / P-trap, which holds water in the pipe. The water prevents odours / gases from travelling through the pipe and into the bathroom. As wet rooms are typically level access, this needs to be incorporated into the floor, where there is not a huge amount of space to install a U-bend / P Trap. To deal with this, most outlets use removable traps which will hold 50mm of water or will have a mechanical spring trap which prevents / blocks odours.
Architect's Wetroom Design Guide
Are you designing a wetroom? Check out our design and inspiration blog, our free design guide or contact us, and we will be happy to assist with design, specification and installation advice.
