Unidrain Wall Mounted Linear drains are the perfect solution for wet rooms with a slope towards the wall. With an extensive range of finishes, this award-winning collection of wall-mounted drains from WM | Wetroom Materials will complement any wet room project on any budget.
Unidrain can be supplied with the new self cleaning trap, click here for more information.
Enlarge image
Unidrain Wall Mounted Linear Wet Room Drains Overview
Click below to view product range on NBS
The Unidrain Wall Mounted Drain collection is approved for both concrete and timber floor installation, so no matter the type of surface you are installing your new wet room on, you can rest assured that your new drain will perform without affecting the construction of your building. All of our drains also come with a 10-year guarantee, so you can trust your new product for years after its installation.
We provide you with all of the technical details and instructions for the perfect installation the first time. From datasheets and DWGs to step-by-step instructions, we understand how important it is to ensure your new wet room drain is installed correctly. That’s why we provide you with all of the information you need to implement the perfect wet room drain from the point of sale.
As a wall-mounted alternative to other wet room drains, fixings are secured tightly to the wall, adding to the general integrity of your wet room drain. It is also easy to achieve a level-access floor should you require a wet room with no slope for wheelchair accessibility.
Provided with an internal channel, this WM collection of Unidrain linear drains prevents stagnant water from forming, helping to prevent the build-up of foul odours and bacteria. Along with an easy-to-remove trap/tile insert, these drains are easy to clean.
A 50mm water seal, along with large flanges to help secure the waterproofing bond to the drain, allow for superior waterproofing qualities for your wet room.
The Unidrain Wall Mounted Drains collection comes with a 48l/min drain outlet as standard, suitable for small to medium wet room drains. If you require something smaller for less demanding projects or need high-capacity drains of up to 102l/min, we have a wide range of drain outlets for you to choose from.
We recommend using the UniSlope 1k system for an easy, fast, and secure installation. Our range of UniSlope boards is manufactured with solid internal cores to avoid crushing whilst maintaining the integrity of the building floor.
When it comes to creating the fall within your wet room, look no further than our LIP 226 specialist wet room screed. Fibre-reinforced, this screed can work from 2mm thick so you don’t have to compromise on space. This is ideal for shallow wet room floors with less room for drainage and other installation parts.
| Model No. | Structural Length | Visual Length | Drain Depth |
Anniversario Kit Order Ref |
Square Kit Order Ref |
Stripe Kit Order Ref |
Coloumn Kit Order Ref |
| 300 | 432 | 300 | 98 | 1004.0300K1 | 1004.0300K1SQ | 1004.0300K1ST | 1004.0300K1CL |
| 600 | 712 | 600 | 102 | 1004.0600K1 | 1004.0600K1CL | ||
| 700 | 812 | 700 | 103 | 1004.0700K1 | 1004.0700K1SQ | 1004.0700K1ST | 1004.0700K1CL |
| 800 | 912 | 800 | 104 | 1004.0800K1 | 1004.0800K1SQ | 1004.0800K1ST | 1004.0800K1CL |
| 900 | 1012 | 900 | 105 | 1004.0900K1 | 1004.0900K1SQ | 1004.0900K1ST | 1004.0900K1CL |
| 1000 | 1112 | 1000 | 106 | 1004.1000K1 | 1004.1000K1SQ | 1004.1000K1ST | 1004.1000K1CL |
| 1200 | 1312 | 1200 | 108 | 1004.1200K1 | 1004.1200K1SQ | 1004.1200K1ST | 1004.1200K1CL |
| 1400 | 1509 | 1400 | 103 | 1004.1400K1 | 1004.1400K1SQ | 1004.1400K1ST | 1004.1400K1CL |
| 1600 | 1709 | 1600 | 104 | 1004.1600K1 | 1004.1600K1SQ | 1004.1600K1ST | 1004.1600K1CL |
| 1800 | 1909 | 1800 | 105 | 1004.1800K1 | 1004.1800K1SQ | 1004.1800K1ST | 1004.1800K1CO |
| 2000 | 2109 | 2000 | 106 | 1004.2000K1 | 1004.2000K1SQ | 1004.2000K1ST | 1004.2000K1CO |
| 2400 | 2509 | 2400 | 108 | 1004.2400K1 | 1004.2400K1SQ | 1004.2400K1ST | 1004.2400K1CO |
| Model No. | Structural Length | Visual Length | Drain Depth |
Kit Order Ref |
| 300 | 432 | 253 | 98 | 1004.0300K2 |
| 600 | 712 | 533 | 102 | 1004.0600K2 |
| 700 | 812 | 633 | 103 | 1004.0700K2 |
| 800 | 912 | 733 | 104 | 1004.0800K2 |
| 900 | 1012 | 833 | 105 | 1004.0900K2 |
| 1000 | 1112 | 933 | 106 | 1004.1000K2 |
| 1200 | 1312 | 1133 | 108 | 1004.1200K2 |
| 1400 | 1509 | 2 x 633 | 103 | 1004.1400K2 |
| 1600 | 1709 | 2 x 733 | 104 | 1004.1600K2 |
| 1800 | 1909 | 2 x 833 | 105 | 1004.1800K2 |
| 2000 | 2109 | 2 x 933 | 106 | 1004.2000K2 |
| 2400 | 2509 | 2 x 1133 | 108 | 1004.2400K2 |
| Model No. | Structural Length | Visual Length | Drain Depth |
Kit Order Ref |
| 300 | 432 | 300 | 98 | 1004.0300K4 |
| 600 | 712 | 600 | 102 | NA |
| 700 | 812 | 700 | 103 | 1004.0700K4 |
| 800 | 912 | 800 | 104 | 1004.0800K4 |
| 900 | 1012 | 900 | 105 | 1004.0900K4 |
| 1000 | 1112 | 1000 | 106 | 1004.1000K4 |
| 1200 | 1312 | 1200 | 108 | 1004.1200K4 |
| 1400 | 1509 | 1400 | 103 | 1004.1400K4 |
| 1600 | 1709 | 1600 | 104 | 1004.1600K4 |
| 1800 | 1909 | 1800 | 105 | 1004.1800K4 |
| 2000 | 2109 | 2000 | 106 | 1004.2000K4 |
| 2400 | 2509 | 2400 | 108 | 1004.2400K4 |
Unidrain Wall Mounted Linear Wet Room Drains Sizes & Finishes
This video is based on installing drain as part of the UniSlope 1K system.
Tiling Highline Panel without Highline Frame
The Unidrain Wall Mounted Drain collection is approved for both concrete and timber floor installation, so no matter the type of surface you are installing your new wet room on, you can rest assured that your new drain will perform without affecting the construction of your building. All of our drains also come with a 10-year guarantee, so you can trust your new product for years after its installation.
We provide you with all of the technical details and instructions for the perfect installation the first time. From datasheets and DWGs to step-by-step instructions, we understand how important it is to ensure your new wet room drain is installed correctly. That’s why we provide you with all of the information you need to implement the perfect wet room drain from the point of sale.
As a wall-mounted alternative to other wet room drains, fixings are secured tightly to the wall, adding to the general integrity of your wet room drain. It is also easy to achieve a level-access floor should you require a wet room with no slope for wheelchair accessibility.
Provided with an internal channel, this WM collection of Unidrain linear drains prevents stagnant water from forming, helping to prevent the build-up of foul odours and bacteria. Along with an easy-to-remove trap/tile insert, these drains are easy to clean.
A 50mm water seal, along with large flanges to help secure the waterproofing bond to the drain, allow for superior waterproofing qualities for your wet room.
The Unidrain Wall Mounted Drains collection comes with a 48l/min drain outlet as standard, suitable for small to medium wet room drains. If you require something smaller for less demanding projects or need high-capacity drains of up to 102l/min, we have a wide range of drain outlets for you to choose from.
We recommend using the UniSlope 1k system for an easy, fast, and secure installation. Our range of UniSlope boards is manufactured with solid internal cores to avoid crushing whilst maintaining the integrity of the building floor.
When it comes to creating the fall within your wet room, look no further than our LIP 226 specialist wet room screed. Fibre-reinforced, this screed can work from 2mm thick so you don’t have to compromise on space. This is ideal for shallow wet room floors with less room for drainage and other installation parts.
| Model No. | Structural Length | Visual Length | Drain Depth |
Anniversario Kit Order Ref |
Square Kit Order Ref |
Stripe Kit Order Ref |
Coloumn Kit Order Ref |
| 300 | 432 | 300 | 98 | 1004.0300K1 | 1004.0300K1SQ | 1004.0300K1ST | 1004.0300K1CL |
| 600 | 712 | 600 | 102 | 1004.0600K1 | 1004.0600K1CL | ||
| 700 | 812 | 700 | 103 | 1004.0700K1 | 1004.0700K1SQ | 1004.0700K1ST | 1004.0700K1CL |
| 800 | 912 | 800 | 104 | 1004.0800K1 | 1004.0800K1SQ | 1004.0800K1ST | 1004.0800K1CL |
| 900 | 1012 | 900 | 105 | 1004.0900K1 | 1004.0900K1SQ | 1004.0900K1ST | 1004.0900K1CL |
| 1000 | 1112 | 1000 | 106 | 1004.1000K1 | 1004.1000K1SQ | 1004.1000K1ST | 1004.1000K1CL |
| 1200 | 1312 | 1200 | 108 | 1004.1200K1 | 1004.1200K1SQ | 1004.1200K1ST | 1004.1200K1CL |
| 1400 | 1509 | 1400 | 103 | 1004.1400K1 | 1004.1400K1SQ | 1004.1400K1ST | 1004.1400K1CL |
| 1600 | 1709 | 1600 | 104 | 1004.1600K1 | 1004.1600K1SQ | 1004.1600K1ST | 1004.1600K1CL |
| 1800 | 1909 | 1800 | 105 | 1004.1800K1 | 1004.1800K1SQ | 1004.1800K1ST | 1004.1800K1CO |
| 2000 | 2109 | 2000 | 106 | 1004.2000K1 | 1004.2000K1SQ | 1004.2000K1ST | 1004.2000K1CO |
| 2400 | 2509 | 2400 | 108 | 1004.2400K1 | 1004.2400K1SQ | 1004.2400K1ST | 1004.2400K1CO |
| Model No. | Structural Length | Visual Length | Drain Depth |
Kit Order Ref |
| 300 | 432 | 253 | 98 | 1004.0300K2 |
| 600 | 712 | 533 | 102 | 1004.0600K2 |
| 700 | 812 | 633 | 103 | 1004.0700K2 |
| 800 | 912 | 733 | 104 | 1004.0800K2 |
| 900 | 1012 | 833 | 105 | 1004.0900K2 |
| 1000 | 1112 | 933 | 106 | 1004.1000K2 |
| 1200 | 1312 | 1133 | 108 | 1004.1200K2 |
| 1400 | 1509 | 2 x 633 | 103 | 1004.1400K2 |
| 1600 | 1709 | 2 x 733 | 104 | 1004.1600K2 |
| 1800 | 1909 | 2 x 833 | 105 | 1004.1800K2 |
| 2000 | 2109 | 2 x 933 | 106 | 1004.2000K2 |
| 2400 | 2509 | 2 x 1133 | 108 | 1004.2400K2 |
| Model No. | Structural Length | Visual Length | Drain Depth |
Kit Order Ref |
| 300 | 432 | 300 | 98 | 1004.0300K4 |
| 600 | 712 | 600 | 102 | NA |
| 700 | 812 | 700 | 103 | 1004.0700K4 |
| 800 | 912 | 800 | 104 | 1004.0800K4 |
| 900 | 1012 | 900 | 105 | 1004.0900K4 |
| 1000 | 1112 | 1000 | 106 | 1004.1000K4 |
| 1200 | 1312 | 1200 | 108 | 1004.1200K4 |
| 1400 | 1509 | 1400 | 103 | 1004.1400K4 |
| 1600 | 1709 | 1600 | 104 | 1004.1600K4 |
| 1800 | 1909 | 1800 | 105 | 1004.1800K4 |
| 2000 | 2109 | 2000 | 106 | 1004.2000K4 |
| 2400 | 2509 | 2400 | 108 | 1004.2400K4 |
Unidrain Wall Mounted Linear Wet Room Drains Sizes & Finishes
This video is based on installing drain as part of the UniSlope 1K system.
Tiling Highline Panel without Highline Frame
Unidrain Wall Mounted Linear Wet Room Drains Datasheet & DWGs
